Battery | Nominal Voltage | 51.2V |
| Voltage Range | 45~57.6V |
| Capacity | 10.24KWH ( 2.5kWH*4 ) |
| Max.discharge Rate | 1C |
| Max.charge Rate | 1C |
| Battery Type | Li-ion(LFP) |
AC Output | Rated Power | 5000W |
| Surge Power | 10000w |
| Output Voltage | 220/230/240Vac±3% |
| Output Current | 22A |
| Rated Frequency | 50/60Hz |
| VTHD | ＜3% |
| Output Wave | Pure Sine Wave |
| Output Type | Euro Round Socket×4+Terminal |
| Max. Efficiency | 93% |
AC Input | AC Input Voltage Range | 170~280Vac |
| AC Input Frequency | 50/60Hz |
| Max AC Charge Current(Battery) | 30A(0~60A Adjustable) |
PV Input | Max. PV Power(Recommended) | 6000W |
| Max. PV Voltage | 450V |
| MPPT Range | 120V~430V |
| Max PV Charge Current(Battery) | 100A |
Operating Conditions | Operating Temperature | 0~55℃ |
| Storage Temperature | -15℃~60℃ |
| Humidity | 5%~95% |
| Cooling Strategy | Fan |
| Weight | Approx. 140KG |
| Dimension [W x H x D, mm] | 620W*345D*780mm |
| Packing | wooden case |
| Packing Dimension [W x H x D] | TBD |
| IP class | IP20 |
| Communication | WIFI/RS485 |
| Warranty | 3 years |
FAQ
Q: Are you a manufacturer or a trade company?
A: We are a manufacture. You are warmly welcome to visit our
factory if you have interest!
Q: Is OEM/ODM available?
A: Yes, it is. Please feel free to tell us your application and
your basic battery requirements.Our R&D team will be pleasure
to provide a full solution to you with these factors taken into
consideration.
Q: Can you provide samples for testing use?
A: Yes, we can. After discussion and designing with our sales and
engineer, we recommend client to order samples first to test our
battery quality and stability.
Q: What security protection function does the PCM have?
A: Short circuit protection, over-current protection, over-load
protection, over-discharge protection, inversely-connection
protection, temperature control, balance, fuse, thermistor, etc.
Our engineer will choose particular function to use for you.
Q: Are there related certificates about battery?
A: If required, we could apply CE, ROHS, CB(IEC62133), UL, KC, PSE,
BIS, UN38.3 etc.
Q: How long for the warranty?
A: Normally 1-3 year.
Q: Which payment methods do you accept?
A: Usually, we accept Western Union, TT, LC. etc.
