ODM 1000W Portable Generator Power Station For Household Power Supply
Basic Info.
Full Charge Time
Approx 6 Hours
Charge Method
Adapter/ Solar Panel/ Car Charger
DC Output
12V/12A (Single Port Max10A)
AC Output
110V/ 60h, 220V/50Hz,1000W,Peak:1300W
USB Output
5V/4.8A (Single Port Max 2.4A )
LED Light
Sos,Lighting,Warnning
Power Display
LCD Display
Product Size
413*207*233mm
Accessory
Power Adapter+Car Charger Cable + User Manual
Product Description
500W portable outdoor emergency energy storage power plant ODM
Basic Info.
Full Charge Time
Approx 6 Hours
Charge Method
Adapter/ Solar Panel/ Car Charger
DC Output
12V/12A (Single Port Max10A)
AC Output
110V/ 60h, 220V/50Hz,1000W,Peak:1300W
USB Output
5V/4.8A (Single Port Max 2.4A )
LED Light
Sos,Lighting,Warnning
Power Display
LCD Display
Product Size
413*207*233mm
Accessory
Power Adapter+Car Charger Cable + User Manual
Product Description
500W portable outdoor emergency energy storage power plant ODM
Specification:
| project | parameter | UA500 | UA1000 |
|
Battery
| Battery class | Lithium ion battery |
| Battery power | 500Wh | 1000Wh |
| Total capacity | 135200mAh | 270,000mAh |
| voltage | 14.8V | 14.8V |
| ampere-hour | 33.8Ah | 67.5Ah |
| cycle life | 800 cycles | 800 cycles |
| BMS | Overvoltage, undervoltage, high and low temperature, three-stage overcurrent, short circuit protection |
|
AC output
| output voltage | 100-240V(Depending on the factory settings in different countries and regions) |
| output frequency | 50-60HZ(Depending on the factory settings in different countries and regions) |
|
output power
| AC500W about 30 Minutes | AC1000W about 5 Minutes |
| AC400W about 65 Minutes | AC800W about 60 Minutes |
| AC300W about 85 Minutes | AC500W about 100 Minutes |
| AC200W about 130 Minutes | AC300W about 160 Minutes |
| AC100W about 270 Minute | AC100W about 540 Minute |
| waveform | Pure sine wave | Pure sine wave |
| efficiency | 70%load:>90% |
|
DC output
| DC5.5 port | DC12V5A |
| Cigarette lighter port | DC12V12A |
| efficiency | 70%load:>93% |
|
USB output
| USB1 | 5V2.4A |
| USB2 | 5V2.4A |
| USB3 | QC3.0,5-12V,18W(MAX) |
| USB-C output | PD3.0 | 5-20V,60W(MAX) |
|
LED lighting
| Low Bright | 5W(MAX) |
| High Bright | 10W(MAX) |
| SOS | NA |
| Flash | NA |
|
Charge
| Adapter | 19V5A about 6h | 19V5A about 12h |
| car | 13V8A about 6h | 13V8A about 12h |
| PV | 24V5A about 7h | 24V5A about 13h |
| Power consumption | Quiescent current | <100uA | <100uA |
| Product weight | Net weight | 5.9KG | 9.9KG |
| Gross weight | 7.6kg | 12KG |
| Product volume | Host | 200*176*146 | 200*294*146 |
| Packing | 340*295*250mm | 450*355*300mm |
|
temperature
| Charge | 0~40ºC(32~104ºF) |
| discharge | -20~50ºC(-4~122ºF) |
| Storage | -20~45ºC(-4~113ºF) |
Function description of front panel
Keys on the front panel are display keys; press the keys to display the electric quantity, power. Functions displayed by LED screen include input information, output information, capacity information, while the running information bar includes overcharge, over discharge, over-temperature.
| NO. | Name | function |
| 1 | charge indicator | Respectively"DC->"/"CAR->"/"PV->",Represents different charging modes. |
| 2 | Electricity Icon | The battery power is displayed in six cells, and the charging will indicate the battery power by running horse. |
| 3 | Battery Indicator | According to the percentage, the battery power is 0%-100%. |
| 4 | Residual time indication | "Time To Full"Display full remaining time,"Time To Empty"Display the remaining time of emptying,The corresponding number will be below+H or M Represents the remaining hours and minutes. |
| 5 | Total power indication | number+Wcombination,Polling shows the total power of charging and discharging, |
| 6 |
Car-Start
| Constant current output |
| 7 | Interface status indication | DC,CAR,USB-A,USB-C,AC,Light,Represents the corresponding interface state. |
| 8 | Car Start State Indicator | The three right-most display combinations, Car-Start/Car-Start Failed/Car-Start Completed, represent that the car is starting and charging, starting and charging fails, starting and charging is completed. |
Function description of front pane
| NO. | Function description |
| 1 | Display screen | 7 | QC3.0 output port |
| 2 | DC switch | 8 | USB-C PD3.0 60W output port |
| 3 | DC5.5 12V output port | 9 | USB 5V2.4A output port |
| 4 | LED Floodlight | 10 | AC switch |
| 5 | Cigarette lighter port | 11 | AC output port |
| 6 | DC input port | 12 | LED switch |
