    Rechargeable Lithium Ion Battery Cell 3.2v 50Ah Solar Energy Storage Systems

    Ask Lasest Price
    Brand Name : Coslight
    Model Number : FP20106308A
    Supply Ability : 1000 Unit/Units per Month
    Price : $42.00 - $44.00/pieces
    • Product Details
    • Company Profile

    Rechargeable Lithium Ion Battery Cell 3.2v 50Ah Solar Energy Storage Systems

    Product Specification
    Item
    Condition / Note
    Specification
    2.1 Capacity
    Nominal charge / discharge at 25℃
    ≥50Ah
    2.2 Nominal Voltage
    Average for nominal discharge
    3.2 V
    2.3 Operating Voltage Range
    0%~100% SOC
    2.50 ~ 3.70 V
    2.4 Nominal Charge
    Constant current
    Constant voltage
    End condition (Cut off)
    25 A (0.5 C) 3.70 V
    1 A

    2.5 Charge Current (25℃)
    Fast Continuous Charge current
    50A (1 C)
    Max Continuous Charge Current
    50A (1 C)
    2.6 Nominal Discharge
    Constant current
    End voltage(Cut off)
    25A (0.5 C)
    2.50 V
    2.7 Discharge Current (25℃)
    Max Continuous Discharge Current
    150A (3C)
    2.8 Weight
    /
    1.22±0.03 kg
    2.9 Operating Temperature
    &Humidity
    Charge
    5 ~ 45℃, ≤85%RH
    Discharge
    -20~60 ℃, ≤85%RH


    2.10 Storage Temperature
    ≤1M
    -20 ~ 60℃, 50%SOC
    ≤3M
    -20 ~ 45℃, 50%SOC

    ≤12M
    -20 ~ 25℃, 50% SOC
    After every tree months, 100% DOD is needed before recharged to 50% SOC
    Dimension





    Overall Dimensions(mm)
    Thickness*Width*Height
    19.8*106*296
    Cell height with terminals
    308
    Distance between terminals
    23.7±0.5;Symmetry
    Center distance of the terminals
    50±0.5
    Terminal position
    Symmetry
    Terminal Length*Width*Height
    (Φ6±0.05)*( 8±1)
    Flatness of terminals
    <0.25
    Length * width of OPSD
    Φ11±0.05
