    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System

    Ask Lasest Price
    Brand Name : Coslight
    Certification : UL
    Model Number : 12V-60Ah
    Supply Ability : 500 Unit/Units per Month
    Price : $143.00 - $148.00/units
    • Product Details
    • Company Profile

    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System

    Product Specification
    ELECTRICAL SPECIFICATIONS
    Nominal Voltage
    12.8 V
    Nominal Capacity @ 0.2C
    60 Ah
    Energy
    768 Wh
    Resistance
    150mΩ
    Cycle Life
    2000+cycles @ 1C 80% DOD
    E⃞iciency
    99%
    Self Discharge
    <3% per Month
    Maximum Modules in Series/Parallels
    4S or 4P
    CHARGE & DISCHARGE SPECIFICATIONS
    Monthly Self Discharge
    Less than 2%
    E⃞iciency of Charge
    100% @ 0.5 C
    E⃞iciency of Discharge
    96 - 99% @ 1 C
    Charge Voltage
    14.6 ± 0.2 V
    Charge Model CC & CV
    0.2C to 14.6 V ,
    then 14.6V, charge current to 0.02C
    Standard Charge Current
    12 A
    Max. Charge Current
    60 A
    Max. Continuous Discharge Current
    60 A
    Peak Discharge Current
    120 A (3S)
    BMS Discharge Cut-o⃞ Voltage
    10 V
    Charge Temperature
    0~45 ℃
    Discharge Temperature
    -20℃ to 60 ℃
    Storage Temperature
    -20℃ to 45 ℃
    MECHANICAL SPECIFICATIONS
    Length
    138± 2 mm
    Width
    229 ± 2 mm
    Height
    205± 2 mm
    Weight
    7 Kg
    Case Material
    ABS
    Terminal
    M5
    Enclosure Protection
    IP65
    COMPLIANCE

    Certifications
    UL1642 (cells)
    IEC62133 (cells)
    Shipping Classification
    UN 3480, CLASS 9
    Products Description
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
    12v 60ah Lithium Iron Phosphate Battery For Motorhome Solar System
