4000 Times Marine Lithium Battery BMS 12V 100Ah LiFePO4 Deep Cycle

Ask Lasest Price
Brand Name :	Coslight or OEM
Model Number :	1260
Certification :	CE,ISO9001,ISO
Price :	Negotiable
Payment Terms :	L/C, D/A, T/T, Western Union
Supply Ability :	8000pcs/week
Delivery Time :	10~15days

Add to Cart

Product Details
Company Profile

4000 Times Marine Lithium Battery BMS 12V 100Ah LiFePO4 Deep Cycle

Electrical Specification		Mechanical Specifications
Nominal Voltage:	25.6V	Dimensions(LWH):	486170240mm
Nominal Capacity	100Ah	Weight:	20KG
Capacity @50A	120min	Terminal Type:	M8/M6
Energy	2560Wh	Case Material:	ABS
Resistance	≤30mΩ @ 50% SOC	Enclosure Protection:	IP65
Efficiency:	99%	Cell Type:	Prismatic
Self Discharge	≤3.5% Per Month	Chemistry:	LifePo4
Maximum Modules in series of Parallel:	8	Configuration:	8S1P

Discharge Specifications		Charge Specifications
Maximum Continuous Discharge Current	100A	Recommend Charge Current	5A-50A
Peak Discharge Current	260A≤5s	Maximum Charge Current	100A
BMS Discharge Current Cut-off	300A±20A [2.2±1ms]	Recommed Charge Voltage	28.4-29.2V
Recommend Low Voltage Disconnect	17.6V	BMS Charge Voltage Cut-off	30V[3.75±0.1V]
BMS Discharge Voltage Cut-off	17.6V[2.2±0.08 vpc] [100±50ms]	Reconnect Voltage	29.2V[3.65±0.1V]
Reconnect Voltage	20V[2.5±0.1vpc]	Balancing Voltage	28.0V[3.5±0.025vpc]
Short Circuit Protection	200-400μs	Balancing Current	35±5mA

Temperature Specifications
Discharge Temperature	-4 to 140℉[-20 to 60℃]
Charge Temperature	32 to 113℉[0 to 45℃]
Storage Temperature	-4 to 113℉[-20 to 45℃]
BMS High Temperature cut-off Discharge	149℉[65℃][Customized]
Reconnect Temperature	122℉[50℃][Customized]
Low Temperature Cut-off Charge	32℉[0℃][Customized]
High Temperature Cut-off Charge	129.2℉[54℃][Customized]

4000 Times Marine Lithium Battery BMS 12V 100Ah LiFePO4 Deep Cycle

FAQ

A): Do you accept small order quantities, how many it is?
Answer: Yes, we accept small order quantities. even 1pc
B): what's the advantage of Pine energy?
Answer: Strong R& D ability and quality assurance
C): Do you accept OEM/ODM?
Answer: We can and be able to provide OEM / ODM service.
D): How long is the warranty period?
Answer: Thank you for your question. We offer 3 or 5 years as the
warranty period depends on customer demand.
E): How long is the warranty period?
Answer: Thank you for your question. We offer 3 or 5 years as the
warranty period depends on customer demand.
F): What’s the factory production capacity
Answer: 2MWH per day for the production capacity. Welcome to visit
our factory and contact us if any further questions
