OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups

    Buy cheap OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups from wholesalers

    Buy cheap OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups from wholesalers
    • Buy cheap OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups from wholesalers
    • Buy cheap OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups from wholesalers
    • Buy cheap OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups from wholesalers

    OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups

    Ask Lasest Price
    Brand Name : Coslight
    Model Number : UPS
    Certification : UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 8000pcs/week
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups

    220V AC Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups


    220V AC to DC 12 Volt mini battery power supply system 5kva 6kva 10kva uninterrupted power supply ups


    Product information



    Exclusive Feature


    1. Pure sine wave output.

    2. Wide AC voltage input range, AVR output.

    3. Adopt traditional EI transformer , stable performance.

    4. LCD/LED&LCD real-time display, concise and straightforward.

    5. Working modes: AC first or battery first optional, intelligent charging.

    6. Built-in MPPT or PWM charge controller optional.

    7. RS232 communication port optional.



    Product Details




    Technical parameter


    Specification

    Product Name

    220V AC to DC 12 Volt mini battery power supply system 5kva 6kva 10kva uninterrupted power supply ups

    Capacity

    6KVA / 4800W

    Toplogy

    Double Conversion Online UPS

    Phase

    Single Phase Input Single Phase Output

    Mains Input

    Wiring

    L/N+PE

    Rated Voltage

    208/220/230/240VAC

    Voltage Range

    90~300VAC

    Frequency Range

    40Hz-70Hz

    Input Power Factor

    ≥0.99

    AC Output

    Wiring

    L/N+PE

    Output Voltage

    208/220/230/240VAC

    Voltage Regulation

    ±1%

    Output Frequency

    50/60±4Hz(Sync Mode) / 50/60Hz±0.1%(Free Run)

    Waveform

    Pure Sine Wave

    Distortion
    (THDV%)

    <2%(Linear Load)

    <7%(None-Linear Load)

    Over load
    capability

    1Min@105%~125%Rated Load
    60Sec.@125%~150%Rated Load
    0.5Sec.@>150%Rated Load

    Efficiency

    AC/AC Mode

    88%

    DC/AC Mode

    86%

    Battery
    &
    Charge

    Rated Battery Voltage ①

    144V / 192V / 240V (DC)

    External

    Battery Capacity

    12V 7Ah x 12 / 16 pieces

    Backup Time

    > 6 mins@ Half load

    Charging Current

    Standard Model with Internal Battery:1A

    Long Backup Time Model :4A

    Physical

    Chassis Style

    Rack-Mounted

    Rack Dimension

    190 x 540x 456 mm

    Weight (kg)

    C6KS: 14.8 kgs

    C6K-12BAT: 37 kgs
    C6K-16BAT: 46.5 kgs

    HMI

    LCD DISPLAY

    Input Mains Voltage, Frequency, Load level, Operation Mode, Health Status

    Standards
    Communication Interface

    1. RS232 PORT

    Optional Extension Card

    2. NMC Card: Support remote monitor the UPS via Smart Phone APP, Web page, PC Monitor Software , Support Server / NAS shutdown
    3. MODBUS Card,
    4. USB Card

    Operating Environment
    Endurance

    Temperature range

    -10~50oC

    Relative Humidity

    0-98% (Non-condensing)

    Acoustics Noise

    <55 DB @ 1 meters



    COMPANY INFORMATION:


    OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups

    OEM Uninterruptible Power System 12V DC Uninterrupted Power Supply UpsOEM Uninterruptible Power System 12V DC Uninterrupted Power Supply UpsOEM Uninterruptible Power System 12V DC Uninterrupted Power Supply Ups



    FAQ

    Q1: Are you a factory or trading company?
    A: We are a professional battery manufacturer with our factory and brand. We provide all kinds of OEM/ODM services for clients, which can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q2.Can I have a sample order?
    A: Yes, we welcome sample orders to test and check quality.

    Q3: Where can I get the price?
    A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.

    Q4. What are your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

    Q5. How about your delivery time?
    A: Generally, it will take 20-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

    Q6. Do you test all your goods before delivery?
    A: Yes, We have a professional QC team to make sure that the product is in good condition before sending out the goods.

    Q7: How do you make our business a long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
